Aruba 2530 Series Fast Ethernet devices are fully managed Layer 2 edge switches delivering cost effective, reliable, and secure connectivity for business networks. This J9782A has 24 x 10/100 ports. Additionally the switch has two 10/100/1000 ports and two dedicated Gigabit SFP ports. Designed for entry level to midsize enterprise networks, these switches deliver full Layer 2 capabilities with enhanced access security, traffic prioritization, and IPv6 host support.
Quick Spec
Figure 1 shows the appearance of Aruba J9782A.
Table 1 shows the quick spec.
|
Product Code |
J9782A |
|
Type |
Aruba 2530-24 Switch |
|
Ports |
|
|
Throughput |
up to 9.5 million pps (64-byte packets) |
|
Switching capacity |
12.8 Gb/s |
|
Dimensions (W x D x H) |
44.2 x 24.64 x 4.45 cm (17.4 x 9.7 x 1.75 in) (1U height) |
|
Weight |
2.59 kg (5.7 lb) |
Product Details
Figure 2 shows the front panel of Aruba J9782A.
Note:
|
① |
Power, Fault, and Locator LEDs |
|
② |
Console Port |
|
③ |
LED Mode select button and indicator LEDs |
|
④ |
24 × RJ-45 autosensing 10/100 ports |
|
⑤ |
Dual-personality ports (10/100/1000BASE-T or SFP) |
Figure 3 shows the back panel of Aruba J9782A.
Note:
|
① |
AC Power Connector |
Compare to Similar Items
Table 2 shows the comparison.
|
Product Code |
J9782A |
|||
|
Type |
Aruba 2530-24-PoE+ Switch |
Aruba 2530-8-PoE+ Switch |
Aruba 2530-48 Switch |
Aruba 2530-24 Switch |
|
PoE power |
195W |
67 W |
N/A |
N/A |
|
Throughput |
Up to 9.5 Mp/s (64-byte packets) |
Up to 4.1 Mp/s (64-byte packets) |
up to 13 million pps (64-byte packets) |
up to 9.5 million pps (64-byte packets) |
|
Switching capacity |
12.8 Gb/s |
5.6 Gb/s |
17.6 Gb/s |
12.8 Gb/s |
Get more information
Do you have any question about the J9782A?
Contact us now via Live Chat or [email protected].
J9782A Specification
J9782A Specifications |
|
| Product Model | Aruba 2530 24 Switch |
| Number of Ports | 24 |
| Ethernet Technology | Fast Ethernet,Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| PoE (RJ-45) Port | No |
| Expansion Slot Type | SFP |
| Form Factor | Rack-mountable,Desktop,Wall Mountable |
| Power Source | Power Supply |
| Layer Supported | 2 |
| Compatible Rack Unit | 1U |
| Number of SFP Slots | 2 |
| Uplink Port | Yes |
| Network Technology | 10/100Base-TX,10/100/1000Base-T |
| Limited Warranty | Lifetime |
| Flash Memory | 128 MB |
| Dimensions (H x W x D) | 1.8'' x 17.4'' x 9.7'' |
| Standard Memory | 256 MB |
| Operating Temperature | 0°C to 45°C |
| Memory Technology | DDR3 SDRAM |
