AIR-AP1572EAC-H-K9 Specification

802.11n Version 2.0 capabilities

●  4x4 MIMO with three spatial streams (3SS)

●  Maximal Ratio Combining (MRC)

●  802.11n and 802.11a/g Beamforming

●  20- and 40-MHz channels

●  PHY data rates up to 450 Mbps (40 MHz with 5 GHz)

●  Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

●  802.11 Dynamic Frequency Selection (DFS)

●  Cyclic Shift Diversity (CSD) support

802.11ac Wave 1 capabilities

●  4x4 MIMO with three spatial streams (3SS)

●  Maximum Ratio Combining (MRC)

●  802.11ac Beamforming

●  20-, 40-, and 80-MHz channels

●  PHY data rates up to 1.3 Gbps (80 MHz with 5 GHz)

●  Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)

●  802.11 Dynamic Frequency Selection (DFS)

●  Cyclic Shift Diversity (CSD) support

DOCSIS 3.0 Capabilities

DOCSIS3.0 with up to 8x4, 16x8, and 24x8 Downstream (DS) x Upstream (US) channel bonding capability for Hybrid Fiber-Coaxial (HFC) Cable Modem (CM) options. The CM protocols include NA-DOCSIS3.0, Euro-DOCSIS3.0 and Japan-DOCSIS3.0. The NA-DOCSIS3.0 is offered with either (42/88 MHz or 85/108 MHz) diplexer split. The Euro and Japan DOCSIS are offered with (65/108 MHz) diplexer split.

NA-DOCSIS3.0, Euro-DOCSIS3.0 24x8 cable modem provides up to:

●  Twenty f our (24) bonded channels on the downstream with total throughput of up to 912 and 1200 Mbps respectively (maximum usable throughput without overhead)

●  Eight (8) bonded channels on the upstream with total throughput of up to 216 Mbps (maximum usable throughput without overhead)

●  Designed to meet DOCSIS 3.0 specifications as well as backward compatibility with existing DOCSIS2.0 networks

●  Enhanced packet processing technology to maximize performance

Channel-bonded cable modems must be used in conjunction with a Cable Modem Termination System (CMTS) that supports channel bonding per the DOCSIS3.0 specifications. When used with a non-channel-bonded CMTS, channel-bonded cable modems function as conventional DOCSIS 2.0 cable modems.

Data Rates Supported

2.4 GHz - 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps

2.4 GHz - 802.11n:

Spatial Streams

MCS Index

GI = 800 ns

GI = 400 ns

20 MHz Rate (Mbps)

20 MHz Rate (Mbps)

1

0

6.5

7.2

1

1

13

14.4

1

2

19.5

21.7

1

3

26

28.9

1

4

39

43.3

1

5

52

57.8

1

6

58.5

65

1

7

65

72.2

2

8

13

14.4

2

9

26

28.9

2

10

39

43.3

2

11

52

57.8

2

12

78

86.7

2

13

104

115.6

2

14

117

130

2

15

130

144.4

3

16

19.5

21.7

3

17

39

43.3

3

18

58.5

65

3

19

78

86.7

3

20

117

130

3

21

156

173.3

3

22

175.5

195

3

23

195

216.7

5 GHz - 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps

5 GHz - 802.11n:

Spatial Streams

MCS Index

GI = 800 ns

GI = 400 ns

20 MHz

Rate (Mbps)

40 MHz

Rate (Mbps)

20 MHz

Rate (Mbps)

40 MHz

Rate (Mbps)

1

0

6.5

13.5

7.2

15

1

1

13

27

14.4

30

1

2

19.5

40.5

21.7

45

1

3

26

54

28.9

60

1

4

39

81

43.3

90

1

5

52

108

57.8

120

1

6

58.5

121.5

65

135

1

7

65

135

72.2

150

2

8

13

27

14.4

30

2

9

26

54

28.9

60

2

10

39

81

43.3

90

2

11

52

108

57.8

120

2

12

78

162

86.7

180

2

13

104

216

115.6

240

2

14

117

243

130

270

2

15

130

270

144.4

300

3

16

19.5

40.5

21.7

45

3

17

39

81

43.3

90

3

18

58.5

121.5

65

135

3

19

78

162

86.7

180

3

20

117

243

130

270

3

21

156

324

173.3

360

3

22

175.5

364.5

195

405

3

23

195

405

216.7

450

5 GHz - 802.11ac:

Spatial Streams

MCS Index

GI = 800 ns

GI = 400 ns

20 MHz

Rate (Mbps)

40 MHz

Rate (Mbps)

80 MHz

Rate (Mbps)

20 MHz

Rate (Mbps)

40 MHz

Rate (Mbps)

80 MHz Rate (Mbps)

1

0

6.5

13.5

29.3

7.2

15

32.5

1

1

13

27

58.5

14.4

30

65

1

2

19.5

40.5

87.8

21.7

45

97.5

1

3

26

54

117

28.9

60

130

1

4

39

81

175.5

43.3

90

195

1

5

52

108

234

57.8

120

260

1

6

58.5

121.5

263.3

65

135

292.5

1

7

65

135

292.5

72.2

150

325

1

8

78

162

351

86.7

180

390

1

9

-

180

390

-

200

433.3

2

0

13

27

58.5

14.4

30

65

2

1

26

54

117

28.9

60

130

2

2

39

81

175.5

43.3

90

195

2

3

52

108

234

57.8

120

260

2

4

78

162

351

86.7

180

390

2

5

104

216

468

115.6

240

520

2

6

117

243

526.5

130

270

585

2

7

130

270

585

144.4

300

650

2

8

156

324

702

173.3

360

780

2

9

-

360

780

-

400

866.7

3

0

19.5

40.5

87.8

21.7

45

97.5

3

1

39

81

175.5

43.3

90

195

3

2

58.5

121.5

263.3

65

135

292.5

3

3

78

162

351

86.7

180

390

3

4

117

243

526.5

130

270

585

3

5

156

324

702

173.3

360

780

3

6

175.5

364.5

-

195

405

-

3

7

195

405

877.5

216.7

450

975

3

8

234

486

1053

260

540

1170

3

9

260

540

1170

288.9

600

1300

Frequency Band and 20- MHz Operating Channels (Regulatory Domains)

-H:

2.412 to 2.462 GHz, 1 channel

5.745 to 5.825 GHz, 5 channels

Note: This varies by regulatory domain. Refer to the product documentation for specific details for each regulatory domain.

Maximum Number of Non-overlapping Channels

2.4
